Review of Nordborg 26

The hull is made of fibreglass. Generally, a hull made of fibreglass requires only a minimum of maintenance during the sailing season. And outside the sailing season, just bottom cleaning and perhaps anti-fouling painting once a year - a few hours of work, that's all.

The interior is like many other boats made of mahogany.
The boat is equipped with 5 berths, a galley and toilet facility.
Note: the boat has also been sold to be self-made/-interiored, which means that the quality of each boat may vary.

The boat equipped with a masthead rig. The advantage of a masthead rig is its simplicity and the fact that a given sail area - compared with a fractional rig - can be carried lower and thus with less heeling moment.

Nordborg 26 is typically equipped with an inboard Volvo Penta MD5A diesel engine at 7.0 hp (5 kW), which gives a max speed about 4.0 knots.

The transmission is a saildrive.

The fuel tank which is made of steel has a capacity of 40 liters (10 US gallons, 8 imperial gallons).

What is Capsize Screening Formula (CSF)?

The capsize screening value for Nordborg 26 is 1.93, indicating that this boat could - if evaluated by this formula alone - be accepted to participate in ocean races.

What is Theoretical Maximum Hull Speed?

The theoretical maximal speed of a displacement boat of this length is 6.3 knots. The term "Theoretical Maximum Hull Speed" is widely used even though a boat can sail faster. The term shall be interpreted as above the theoretical speed a great additional power is necessary for a small gain in speed.

The immersion rate is defined as the weight required to sink the boat a certain level. The immersion rate for Nordborg 26 is about 119 kg/cm, alternatively 667 lbs/inch.
Meaning: if you load 119 kg cargo on the boat then it will sink 1 cm. Alternatively, if you load 667 lbs cargo on the boat it will sink 1 inch.

What is Motion Comfort Ratio (MCR)?

The Motion Comfort Ratio for Nordborg 26 is 20.7.

Comparing this ratio with similar sailboats show that it is more comfortable than 58% of all similar sailboat designs. This comfort value is just above average.

What is L/B (Length Beam Ratio)?

The l/b ratio for Nordborg 26 is 3.06.

Compared with other similar sailboats it is slimmer than 58% of all other designs. It seems that the designer has chosen a slightly more speedy hull design.

What is Displacement Length Ratio?

The DL-ratio for Nordborg 26 is 217 which categorizes this boat among 'light crusers & offshore racers'.

58% of all similar sailboat designs are categorized as heavier. A light displacement requires less sailarea and has higher accellerations.

What is Relative Speed Performance?

The Relative Speed Performance for Nordborg 26 is 38

The relative speed performance is 38 which means that a it is faster than 38% of all similar sailboat designs.

If you need to renew parts of your running rig and is not quite sure of the dimensions, you may find the estimates computed below useful.

This section is reserved boat owner's changes, improvements, etc. Here you might find (or contribute with) inspiration for your boat.

Do you have changes/improvements you would like to share? Upload a photo and describe what you have done.

We are always looking for new photos. If you can contribute with photos for Nordborg 26 it would be a great help.

If you have any comments to the review, improvement suggestions, or the like, feel free to contact us. Criticism helps us to improve.

[Ref 1]: ISO 8666 Small craft — Principal data.
[Ref 3]: ISO 12215-5 Small craft — Hull construction and scantlings.
